Propelling Next-Gen 800V Electric Mobility
한계를 뛰어넘는 차세대 800V SiC 전력 모빌리티 솔루션
Hypercar-class Tier-1 powertrain engineering. Integrating ultra-low loss 1,200V Silicon Carbide (SiC) power modules, 32,000 RPM continuous hairpin motors, and megawatt bi-directional charging architecture for hypercars and mission-critical commercial platforms. (가상 브랜드 샘플 — 화면의 사양은 모두 예시 수치입니다.)
- 800V SYSTEM STATUS:
- ACTIVE // NOMINAL
- POWER DELIVERY:
- 720 kW PEAK
- MOTOR TEMP:
- 45°C (GLYCOL LOOP)
- BATTERY SOC:
- 88.4%
- INV EFFICIENCY:
- 98.7% @ 120kHz
- TORQUE VECTORING:
- SUB-MILLISECOND ON
- V_DS // I_PK:
- 804V // 920A
- SWITCHING TIME:
- 14.2 ns
- THERMAL CONDUCTANCE:
- 0.12 K/W
아래 수치는 모두 예시 계측값입니다.
SiC conversion rate minimizing parasitic thermal loss via planar busbar integration. (예시 수치)
10% to 80% State of Charge (SoC) replenishment utilizing native 800V DC bus continuous absorption. (예시 수치)
612 PS with 920 Nm instantaneous torque density, validated across continuous high-speed circuit hot-laps. (예시 수치)
Co-axial 3-in-1 e-Axle structural integration discarding external HV harness copper weight. (예시 수치)
800V Ultra-Fast Charging & Thermal Simulator
800V 초급속 충전 프로파일 및 액체 냉각 루프 발열 시뮬레이션 — 브라우저 안에서 도는 예시 계산이며 실제 계측값이 아닙니다
Explosive Powertrain Architecture Component Explorer
모빌리티의 물리적 한계를 재정의하는 3대 핵심 서브시스템: 1,200V SiC 인버터, 32,000 RPM 헤어핀 모터, 지능형 800V 전력 분배 BMS.
1,200V Silicon Carbide (SiC) Power Inverter
Proprietary micro-trench planar SiC MOSFET dies delivering up to 70% switching loss abatement over conventional IGBT modules. Engineered with double-sided direct water-glycol pin-fin cooling.
32,000 RPM Continuous Hairpin Stator Motor
Utilizing 97.4% slot fill factor rectangular flat copper conductors. Equipped with hollow-shaft rotor oil-jet impingement cooling and dual ASIL-D resolver sensors for millisecond torque response.
800V High-Voltage Integrated Junction & BMS
Ultra-fast pyro-fuse emergency isolation actuated in sub-2ms under short-circuit anomalies. Contactless fluxgate current sensing paired with bi-directional 22kW V2G/V2X onboard power export.
Global OEM Compliance & Powertrain Validation
Every Voltron 800V component conforms stringently to worldwide Tier-1 automotive functional safety, discrete semiconductor endurance, and cybersecurity frameworks. 가상 브랜드 샘플이라 아래 인증 배지와 시험 조건은 모두 예시 수치·예시 표기입니다.
ISO 26262 ASIL-D (예시 표기)
Highest functional safety integrity level assessed by an international certification body (예시 표기) for dual-inverter fail-operational architectures.
AEC-Q101 Grade 0 (예시 표기)
Discrete automotive qualification tested up to 2,000 thermal cycles at extreme junction extremes (-40°C to +175°C).
UNECE R100 Rev 3 (예시 표기)
Electric vehicle electrical safety approval compliant across European, Korean (KMVSS), and North American standards.
ISO/SAE 21434 (예시 표기)
End-to-end vehicle cybersecurity engineering protecting CAN-FD and Automotive Ethernet telemetry nodes from intrusion.
Voltron 2026 SiC Powertrain Whitepaper
Comprehensive 96-page engineering compilation (예시) detailing 1,200V trench gate capacitance, thermal transient FEM analyses, and hairpin stator slot fill benchmarking.
Confidential OEM RFQ & Engineering Consultation
비공개 견적 및 맞춤형 전력반도체 파워트레인 아키텍처 수주 개발을 위한 최고 엔지니어링 디렉터 직통 채널입니다.
